CNC Gantry machine
5 axis gantry
Crossbeam Moving Five Axis Gantry machining center
HCNT-CMS5A series
Technical Parameters
|
Parameters |
Unit |
CMS5A 40 / 60 / 8025 |
CMS5A 40 / 60 / 8030 |
CMS5A 40 / 60 / 8035 |
CMS5A 40 / 60 / 8040 |
|
Worktable area |
mm |
4000 / 6000 / 8000×2500 |
4000 / 6000 / 8000×3000 |
4000 / 6000 / 8000×3500 |
4000 / 6000 / 8000×4000 |
|
Max. worktable loading |
t |
30 / 40 / 55 |
40 / 50 / 65 |
50 / 60 / 75 |
60 / 70 / 85 |
|
X/Y/Z travel |
mm |
4200 / 6200 / 8200×2500×1500 |
4200 / 6200 / 8200×3000×1500 |
4200 / 6200 / 8200×3500×1500 |
4200 / 6200 / 8200×4000×1500 |
|
Guideway |
|
X: 2 linear guide way on each side Y: 4 heavy-duty linear roller guide way Z: 4 linear roller guide way |
|||
|
Dist. from spindle nose to table surface |
mm |
150-1650 (customizable) |
|||
|
Spindle |
|
B head (standard) C / D head (optional) |
|||
|
Tool magazine capacity |
position |
20×1 unit (Max. 20×4 units) |
|||
|
Max. loading height |
mm |
1500 (customizable) |
|||
|
Max. loading width |
mm |
3300 |
3800 |
4300 |
4800 |
|
Feeding speed |
m/min |
0-20 |
|||
|
Rapid speed |
m/min |
40 / 40 / 20 |
|||
|
Positioning accuracy |
mm |
0.01 |
|||
|
Repeat positioning accuracy |
mm |
0.005 |
|||
|
Weight of machine |
t |
60 / 75 / 95 |
63 / 78 / 98 |
67 / 82 / 102 |
70 / 85 / 106 |
|
Dimension (without electric cabinet) |
mm |
9090 / 11080 / 13080×6800×5600 |
9080 / 1080 / 13080×7300×500 |
9080 / 11080 / 13080×7800×5600 |
980 / 11080 / 13080×8300×5600 |
|
Control system |
|
5-axis simultaneous standard Siemens ONE / Heidenhain |
|||
Processing Example
