Automation
HCNT-ARP / HCNT-ALP
HCNT-ARP HCNT-ALP
Technical Parameters
|
Technical parameters |
HCNT-ARP260 |
HCNT-ARP800 |
HCNT-ARP1500 |
|
HCNT-ALP260 |
HCNT-ALP800 |
HCNT-ALP1500 |
|
|
MAX. workpiece weight (kg) |
260 |
800 |
1500 |
|
Single storage location load (kg) |
300 |
1000 |
1800 |
|
Loading station load (kg) |
300 |
1000 |
1800 |
|
Applicable models |
Full range of milling processing centers |
||
HCNT-AMC
Technical Parameters
|
Technical parameters |
HCNT-AMC30 |
HCNT-AMC100 |
|
MAX. workpiece weight (kg) |
30 |
100 |
|
Single storage location load (kg) |
40 |
120 |
|
X/Z travel (mm) |
1700/250 |
1700/300 |
|
Applicable models |
HCNT-MU50, HCNT-MU50E HCNT-MG80, HCNT-MG80T |
|
HCNT-AET
Technical Parameters
Technical parameters
HCNT-AET80
HCNT-AET120
Number of tool positions (pieces)
80
120
Single storage position load (kg)
30
30
MAX. tool length allowed (mm)
450
450
Applicable tool holders
BT、SK、CAPTO、BBT、HSK tool holders
Can be customized according to actual conditions
